Resmed Airmini
Manuals, Downloads, & Resources

Setting up the machine
1. Plug the power supply unit into the machine and then into the power outlet.
2. Connect the gray end of the air tubing to the machine.

Adding optional waterless humidification (for AirFit N20 or AirFit P10 for AirMini only):
1. To use the optional HumidX™ or HumidX Plus, twist open the connector.
2. Insert the HumidX or HumidX Plus inside with the blue or gray side facing down towards the tube.
3. Close the connector by twisting its ends back together until they lock into place.

Connecting the machine and smart device
1. Ensure you have the latest version of the AirMini app installed on your smart device. If not, download it from the App Store or Google Play depending on your device.
2. Also ensure Bluetooth is enabled on your smart device. Refer to your smart device’s user guide for instructions as needed.
3. Open the AirMini app and you’ll be greeted with a welcome screen.
4. Accept ResMed's Terms and Conditions and Privacy Policy to continue.
5. When prompted by the AirMini app, press the Bluetooth button on the AirMini machine.
6. When the light on the machine flashes blue, Bluetooth is enabled  and it is ready to connect.
7. On the smart device, tap Connect.
8. Wait until the machine appears in the accessory selection list.
9. Select the machine from the list to connect.

Authenticating your device
1. The first time you pair the machine with your smart device, you will need to authenticate it by entering the four-digit key located on the bottom of the machine.
2. When successfully connected, the Bluetooth connection icon will appear in the top right corner of the screen.

Starting therapy on the Sleep screen
1. Enter the Sleep screen by pressing on Sleep on the Navigation tab.
2. The Sleep screen is split into two tabs, Therapy and Mask Fit. You can toggle between the Therapy screen, to access comfort settings, and the Mask Fit screen, to check for air leaks around the mask.
3. To start therapy, press Start on your Therapy screen.
4. To stop therapy, press Stop from the same menu.

Adjusting comfort settings
1. Enter the Sleep screen and click on Options in the Therapy screen.
2. Tap the setting you wish to adjust.
3. Use the spinner or switches to select the required setting.
4. Repeat this process for as many settings as needed.

The Dashboard
1. Enter your Dashboard screen by pressing on Dashboard in the Navigation tab. If the AirMini machine is connected to the AirMini app, the Dashboard will provide you with summary data and a score for the recent therapy session.
2. You can also access the previous days' information by clicking on the dropdown arrow next to the current date.
3. Tap on any therapy session to view the score and sleep data for that date.

For AirFit™ N20 users
Note: Do not wash or wet the HumidX™ or HumidX Plus. When not in use, store in a clean and dry place.

1. Clean and check the AirFit N20 connector by hand daily. Never wash it using a dishwasher or washing machine.
2. Wash the connector in warm water (~30°C or 86°F) and mild liquid detergent.
3. Clean the connector using a soft bristle brush, with particular attention paid to the vent holes on the inside.
4. Rinse well under running water, then shake to remove excess water.
5. Air-dry out of direct sunlight, and check for dirt or dust before use.

For AirFit™ F20 users
1. Clean and check the AirFit F20 connector by hand daily. Never wash it using a dishwasher or washing machine.
2. Wash the connector in warm water (~30°C or 86°F) and mild liquid detergent.
3. Clean the connector using a soft bristle brush, with particular attention paid to the vent holes on the outside.
4. Rinse well under running water, then shake to remove excess water.
5. Air-dry out of direct sunlight, and check for dirt or dust before use.

AirMini tubing
1. Clean and check the AirMini tubing by hand weekly. Never wash it in a dishwasher or washing machine.
2. Soak and wash the tubing in warm water (~30°C or 86°F) and mild liquid detergent.
3. Rinse well inside and out under running water.
4. Hang the tubing so that each end can drain, and leave it to air-dry out of direct sunlight.
5. Clean the AirMini by wiping down each side of its exterior carefully with a dry cloth.

1. To insert the optional HumidX™ or HumidX Plus, for AirFit™ N20 or AirFit P10 forAirMiniusers, open the connector by gently twisting.
2. Grip the HumidX or HumidX Plus at the edges, with the blue and gray side facing down towards the tube, and place it inside.
3. Close the connector by twisting its ends back together until they lock into place.
4.HumidX and HumidX Plus must be discardedand replaced within 30 days of opening the HumidX or HumidX Plus packaging.

For AirFit™ F20 users
1. Check the AirFit F20 connector daily for signs of damage or blockages caused by dirt and dust.
2. The connector should be replaced at least every six months or if there are signs of damage.

For AirFit N20 users
1. Check the AirFit N20 connector daily for signs of damage or blockages caused by dirt and dust.
2. The connector should be replaced at least every six months or if there are signs of damage.

AirMini tubing
1. Check the AirMini tubing daily for any holes, tears or cracks.
2. The tubing should be replaced at least every six months or if there are signs of damage.

AirMini air filter
1. Check the AirMini air filter for any holes, tears, cracks, or blockages caused by dirt or dust.
2. The air filter should be replaced at least every six months or if there are signs of damage. It cannot be washed.
3. To change the air filter, slide the air filter cover off and replace the old air filter with a new one.
4. Reattach the air filter cover, and ensure it is fitted at all times to prevent water and dust from entering the machine.

HumidX™ and HumidX Plus
1. Check your HumidX or HumidX Plus daily for signs of damage or blockages caused by dirt and dust. They cannot be washed.
2. HumidX and HumidX Plus must be replaced within 30 days after opening the packaging or if there are signs of damage.
